TFT LCD 3,2″ Shield+Touch Screen SD Reader for Arduino 2560

475 kr

SainSmart Mega2560+3.2″ TFT LCD Shield+Touch Screen SD Reader for Arduino 2560

Tilgjengelighet 1 på lager

Kategori:

Sender istedet 2,8″ TFT SHIELD + Keyestudio mega2560 advanced og ett stk shield til å ha imellom som bildet viser pga minker på utvalget.
SainSmart Mega2560 + 3.2LCD TFT Touch Screen SD Reader For Arduino R3 Robot Attention please:SD card supports Mega 2560, ARM and 51 MCU. SD Memory Supports:2GB please use the Software version : 0023
The SainSmart Mega 2560 is a microcontroller board based on the ATmega2560. It contains everything needed to support the microcontroller; simply connect it to a computer with a USB cable or power it with a AC-to-DC adapter or battery to get started. The Mega is compatible with most shields designed for the SainSmart Duemilanove or Diecimila. SainSmart 3.2″ TFT LCD Display is a LCD touch screen module. It has 40pins interface and SD card and flash reader design. It is a powerful and multifunctional module for your project. The TFT shield is 100% compatible for the Mega2560 to expend more Pins
SainSmart 3.2 TFT LCD Display 1. SainSmart 3.2″ TFT LCD Display is a LCD touch screen module. It is a powerful and multifunctional module for your project. The Screen include a controller SSD1289, it’s a support 8/16bit data interface, easy to drive by many MCU like STM32, AVR and 8051. It is designed with a touch controller in it. The touch IC is XPT2046 , and touch interface is included in the 40 pins breakout. It is the version of product only with touch screen and touch controller. 2.Size: 3.2 inch 3.240 x 320 QVGA resolutions. 4. 65K true to life colors. 5. TFT screen with SD card reader. 6. The LCD has a wide viewing angle; the contrast is also very suitable. 7. This TFT LCD Screen Module, 40pins interface, not just a LCD screen but include the Touch, SD card and Flash design. So it’s a powerful extension module for your project. 8. Attention please: SD card supports Mega 2560, ARM and 51 MCU. SD Memory Supports:<=2GB. Please use the Arduino Software version: 0023/0022
